Singer 1408 User Manual

17
1
2
3
Raising the Bobbin Thread
Hold the upper thread with the left hand. Turn the handwheel
(1) towards you (counterclockwise) lowering, then raising
needle.
If it is difficult to raise the bobbin thread, check to make sure
the thread is not trapped by the hinged cover or the
Removable Extension Table.
Gently pull on the upper thread to bring the bobbin thread up
through the needle plate hole. (2)
Lay both threads to the back under the presser foot. (3)
Note:
EN

Singer 1408 Specifications

General

Free Arm	Yes
Built-in Needle Threader	No
Reverse Stitch	Yes
Type	Mechanical
Built-in Stitches	8
Stitch Width	5 mm
Presser Feet	All-purpose foot, zipper foot, buttonhole foot, button sewing foot
Buttonhole Type	4-Step
Bobbin Type	Front-loading
Included Accessories	Needles, bobbins, screwdriver, seam ripper, lint brush
Weight	7 kg
