Singer 1408 User Manual

Changing the Bulb
1
3
2
50
Disconnect the machine from the power supply by removing
the plug from the main socket!
Replace bulb with same type rated 10 watts (110-120V area)
or 15 watts (220-240V area).
- Loosen screw (A) as illustrated. (1)
- Remove the face plate (B). (2)
- Unscrew the bulb and install a new one (C). (3)
- Replace the face plate and tighten screw.
Should there be any problem, consult your SINGER
retailer.
®
authorized
C
B
A
EN

Singer 1408 Specifications

General

Free Arm	Yes
Built-in Needle Threader	No
Reverse Stitch	Yes
Type	Mechanical
Built-in Stitches	8
Stitch Width	5 mm
Presser Feet	All-purpose foot, zipper foot, buttonhole foot, button sewing foot
Buttonhole Type	4-Step
Bobbin Type	Front-loading
Included Accessories	Needles, bobbins, screwdriver, seam ripper, lint brush
Weight	7 kg
