Singer 2250 User Manual

Disconnect the machine from the power supply by removing
the plug from the main socket!
Replace bulb with same type rated 10 watts (110-120V area)
or 15 watts (220-240V area).
- Loosen screw (A) as illustrated. (1)
- Remove the face plate (B).
- Unscrew the bulb and install a new one (C). (2)
- Replace the face plate and tighten screw.
Should there be any problem, consult your Singer retailer.
12
Changing the bulb
GB
1
2
C
A
B

Singer 2250 Specifications

General

Buttonhole Style	4-step
Free Arm	Yes
Built-in Light	Yes
Type	Mechanical
Stitch Width	5 mm
Buttonhole Styles	1
Needle Positions	Variable
Built-in Needle Threader	No
Maximum Stitch Length	4 mm
Maximum Stitch Width	5 mm
Bobbin Type	Front-loading
Stitch Options	Basic
Presser Feet Included	All-purpose, zipper, buttonhole
Weight	13 pounds
