Singer 2250 User Manual

20
GB
Inserting the bobbin
12
6
3
4
5
a
When inserting or removing the bobbin, the needle must
be fully raised.
Attention:
- Open the hinged cover. (1)
- Pull the bobbin case tab (a) and remove the bobbin case. (2)
- Hold the bobbin case with one hand. Insert the bobbin so
that the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the finger. (4)
Leave a 6 inch tail of thread.
- Hold the bobbin case by the hinged latch. (5)
- Insert it into the shuttle. (6)
Turn power switch to off ("O") before inserting or
removing the bobbin.

Singer 2250 Specifications

General

Buttonhole Style	4-step
Free Arm	Yes
Built-in Light	Yes
Type	Mechanical
Stitch Width	5 mm
Buttonhole Styles	1
Needle Positions	Variable
Built-in Needle Threader	No
Maximum Stitch Length	4 mm
Maximum Stitch Width	5 mm
Bobbin Type	Front-loading
Stitch Options	Basic
Presser Feet Included	All-purpose, zipper, buttonhole
Weight	13 pounds
