14
WINDING THE BOBBIN
1. Place a spool of thread on the spool pin, and secure it with
the spool pin cap. Pull the thread out from the spool and
place it through thread guides as shown in illustration.
2. Put end of thread through the hole in bobbin as shown.
3. Push bobbin winder shaft to far left position, if it is not
already there. Place bobbin onto shaft with end of thread
coming from top of bobbin. Push bobbin winder shaft to the
right until it clicks. Hold onto end of thread.
4. Start machine. After the bobbin has begun to ll, stop to cut
the thread tail. Step on the foot control again to continue
to ll the bobbin. The bobbin will automatically stop turning
when completely filled. Push shaft to the left to remove
bobbin and cut thread.
Be sure to use Class 15 J bobbins.
1
2
3
4
Note: Make sure the presser foot is down.
