– 17 –
1 INTRODUCTION
OVERVIEW
The EZ Switch 10/100 SMCFS801P PoE switch provide 8 or 10/100 Mbps auto-
negotiating RJ-45 ports. Each port on the switches support auto MDI/MDI-X,
which eliminates the need for crossover cables or uplink ports. The switches are
plug-and-play; any port can be connected to a server, a hub, or a switch, using
straight-through or crossover cable.
FEATURES
◆ Complies with IEEE 802.3 and IEEE 802.3u standards
◆ 8 10/100 Mbps auto-negotiating RJ-45 ports supporting Auto-MDI/MDIX
◆ Supports PoE power up to 30 Watts on 4 ports, 15.4 Watts on 8 ports, or 7.5
Watts on 8 ports
◆ PoE total power budget 105W for all PoE ports
◆ Supports IEEE 802.3x flow control for full-duplex mode and backpressure
for half-duplex mode
◆ LED indicators for monitoring power, link, activity
◆ Rack-mountable steel case
◆ Support for Green Saving, which can save up to 60% of power consumption
