IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
4.2.29 PRDID WITH CHECKSUM
Available from firmware 2.98
The default SMC pitch rotation direction definition differs from PRDID format definition. By this
reason the axis inversion checkbox for Pitch must be ticked to have the correct rotational direction as
per the PRDID string definition, where positive Pitch is bow up. Use the SMC IMU Configuration
Software to change the inverted Pitch if required. As default when selecting the PRDID string the
configuration software will tick the checkbox for the pitch axis inversion.
Data Frame
$PRDID,±yy.yy,±xx.xx,±hhh.hh*cs<CR><LF>
Example
$PRDID,+05.42,+00.15,347.94*73
Bitrate
Max output Rate
115200
100
57600
100
38400
100
19200
57
9600
28
4800
14
Description
Form
Start Characters
$PRDID
Pitch Angle (yy.yy)
Degrees Resolution 0.01° (+ve=bow up)
Roll Angle (xx.xx)
Degrees Resolution 0.01° (+ve=port up)
Heading (hhh.hh)
Heading Resolution 0.01°
Checksum (cs)
*cs
Termination Characters
<CR><LF>
