Modeofswitchoutput
ThefollowingoperationtypesareavailablebysettingP1andP2.
Note). This function is available for monitor output: switch output type
(ITV※0※※-※2andITV※0※※-※3).

■P1＜P2： ■P1≧P2：
Windowcomparatormode Hysteresismode


ON
OFF
P1
P2

ON
OFF
P1
P2



Output pressure of
E/Pregulator
Switchoutput

■P1＝P2＝0：Outofrangemode
（Theswitchoutputturnsonwhensetpressureisachieved.）


ON
OFF


Switchoutput
Output pressure of
E/Pregulator
In
p
utsi
g
nal

―10―
