VorTek ProtoCessor Start-up Guide 54
Point Status Actual Flow
BI
9
04105.13
Point Status Actual Valve Position
BI
10
04105.14
Point Status Control Setting Value
BI
11
04105.15
Energized Time
AI
12
04114-04115
Operating Time
AI
13
04116-04117
Operating Level
AI
14
04118-04119
Number Of Operations
AI
15
04120-04121
Number Of Reverse
AI
16
04122-04123
Total Operating Time Within Range 1
AI
17
04124-04125
Total Operating Time Within Range 2
AI
18
04126-04127
Total Operating Time Within Range 3
AI
19
04128-04129
Total Operating Time Within Range 4
AI
20
04130-04131
Total Operating Time Within Range 5
AI
21
04132-04133
Cooling/Heating Status
BV
22
04134
Dev Status Reverse Flow Error
BI
23
04135.1
Dev Status Pressure Sensor Error
BI
24
04135.2
Dev Status Control Method Setting
BI
25
04135.3
Dev Status Fully Close Error
BI
26
04135.4
Dev Status Potentiometer Error
BI
27
04135.5
Dev Status Operation Failure
BI
28
04135.6
Dev Status Unmatched Pos Detection
BI
29
04135.7
Dev Status RS-485 Comm Error
BI
30
04135.11
Dev Status Minor Error 2
BI
31
04135.12
Dev Status Minor Error 1
BI
32
04135.13
Actual Flow
AI
33
04155
Set Flow
AI
34
04156
Supply Temperature
AI
35
04157
Return Temperature
AI
36
04158
Valve Inlet Pressure
AI
37
04159
Valve Outlet Pressure
AI
38
04160
Energy
AI
39
04161
Totalized Flow (Cooling)
AI
40
04162-04163
Totalized Flow (Heating)
AI
41
04164-04165
Totalized Energy (Cooling)
AI
42
04166-04167
Totalized Energy (Heating)
AI
43
04168-04169
11.3 U42_U43 Modbus RTU Mappings to Modbus and BACnet
Point Name
BACnet Data Type
BACnet Object ID
Modbus Register
Volume Flow Rate
AI
1
40005/40006
Velocity
AI
2
40007/40008
Positive Total
AI
3
40009/40010
Positive Total – exponent
AI
4
40011
Negative Total
AI
5
40012/40013
Negative Total – exponent
AI
6
40014
Net Total
AI
7
40015/40016
Net Total – exponent
AI
8
40017
Energy flow
AI
9
40018/40019
Energy Total (hot)
AI
10
40020/40021
Energy Total (hot) – exponent
AI
11
40022
Energy Total (cold)
AI
12
40023/40024
Energy Total (cold) – exponent
AI
13
40025
Up Signal Int
AI
14
40026/40027
Down Signal Int
AI
15
40028/40029
Quality
AI
16
40030
Error Code
AI
17
40031
Flow Velocity Unit
AI
18
40060/40061
Flow Rate Unit
AI
19
40062/40063
Flow Total Unit
AI
20
40064
Energy rate Unit
AI
21
40065/40066
Energy Total Unit
AI
22
40067
Analog Input AI1 Value
AI
23
40074/40075
Analog Input AI2 Value
AI
24
40076/40077
4 - 20 mA Value
AI
25
40078/40079
