PROGRAMMING OF N° 2 ANALOG OUTPUT (OUt 2 20 MA TYPE)5
Proceed as for number 1 analog output. If you do not wish to use it, press ▼ to return to network programming (Net)
or to pass to number 3 analog output programming (if the 2
nd
0/4 – 20 mA module is installed) or press for 3 seconds
on
PROG to quit programming.
PROGRAMMING OF N° 3 ANALOG OUTPUT (OUt 3 20 MA TYPE)6
7
Proceed as for number 1 analog output. Number 3 output is present while installing a 2
nd
analog output module. If you
do not wish to use it, press ▼ to pass to number 4 analog output programming (OUt 4 – 20 MA TYPE) or press for 3
seconds on PROG to quit programming.
PROGRAMMING OF N° 4 ANALOG OUTPUT (OUt 4 20 MA TYPE)
Proceed as for number 1 analog output. Number 4 output is present while installing a 2
nd
analog output module. If you
do not wish to use it, press ▼ to return to network programming (Net) or press for 3 seconds on PROG to quit pro-
gramming.
TECHNICAL CHARACTERISTICS
ANALOG OUTPUTS
Load resistance 0 to 600 Ohms
Response time 1 sec
Galvanic insulation 2.5 kV
Accuracy (full scale) 0.5%
