Sony Bravia KDL-75W850C User Manual

11
US
US
Connecting the TV
For more information on connections, refer
to the Help Guide.
Note
• Use an antenna cable connector no greater than
14 mm thick.
• When connecting the cable to the Cable/
Antenna, input finger tighten only, over
tightening the connection can damage the TV.
• Use an HDMI cable connector within 12 mm
(thickness) × 21 mm (width).
Recommendation for an F type plug
Projection of the inner wire from the
connection part must be less than 1.5 mm.
(Reference drawing for an F type plug)
1.5 mm max.
7 mm max.
Showing a Set Top Box with HDMI
connection
Set Top Box

Sony Bravia KDL-75W850C Specifications

General

Screen Type	led
Wall Mount	400mm x 300mm
Tuner	digital
Screen Size	74.5 inches, 75 inches
Refresh Rate	120hz
Closed Captioning	yes
HDR	no
Built-In Speakers	yes
Surround Sound	dolby digital plus, dolby pulse, surround sound
Speakers Output	20 watts
USB Ports	2
RF Antenna	yes
Network	built-in wi-fi
Headphones Output	yes
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	sony smart tv
Remote Control	standard
3D	yes
Power Consumption	250 kilowatt hours
Depth with Stand	13 inches
Height with Stand	40 inches
Width with Stand	66 inches
Net Weight with Stand	76.9 pounds
Depth without Stand	3.125 inches
Height without Stand	38.25 inches
Net Weight without Stand	74.3 pounds
