The illumination LED is turned on.
ˎ If you do not wish to light up the illumination
LED, you can turn it off.
Press HOME, then select [Settings]
[Illumination LED]
[Off].
Cannot connect to a wireless router by
WPS (Wi-Fi Protected Setup).
ˎ If you use WEP security, select [Easy]
[Wi-Fi] [Connect by scan list]. Then, select
the network name (SSID) you want to
connect.
Cannot find the required network name
in network setup.
ˎ Select [[Manual entry]] and press to enter
network name.
Specifications
System
Television system
NTSC: American TV standard
ATSC (8VSB terrestrial): ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000 (Does not
include CableCARD functionality)
Channel coverage
Analog terrestrial: 2 - 69 / Digital terrestrial:
2 - 69
Analog Cable: 1 - 135 / Digital Cable: 1 - 135
Panel system
LCD (Liquid Crystal Display) Panel, LED
Backlight
Speaker output
10 W + 10 W
Wireless technology
Protocol IEEE802.11a/b/g/n
Bluetooth Version 4.1
Input/Output jacks
CABLE/ANTENNA
75-ohm external terminal for RF inputs
VIDEO IN
Video / Audio input (phono jacks)
COMPONENT IN
YPBPR (Component Video): 1080p (60 Hz),
1080i (60 Hz), 720p (60 Hz), 480p, 480i
Audio input (phono pin jack)
HDMI IN 1/2/3/4
Video (2D):
1080p (30, 60 Hz), 1080/24p, 1080i (60 Hz),
720p (30, 60 Hz), 720/24p, 480p, 480i, PC
Formats
Video (3D):
Frame Packing: 1080p (30 Hz), 1080/24p,
1080i (60 Hz), 720p (30, 60 Hz), 720/24p
Side-by-Side: 1080p (60 Hz), 1080/24p, 1080i
(60 Hz), 720p (60 Hz)
Over-Under: 1080p (30, 60 Hz), 1080/24p,
1080i (60 Hz), 720p (60 Hz)
Audio: 5.1 channel linear PCM: 32, 44.1, 48,
88.2, 96, 176.4 and 192 kHz, 16, 20 and 24
bits, Dolby Digital and DTS
ARC (Audio Return Channel) (HDMI IN 4 only)
MHL (common with HDMI IN 1)
Video (2D):
1080p (30 Hz), 1080/24p, 1080i (60 Hz),
720p (30, 60 Hz), 720/24p, 480p, 480i
Video (3D):
Side-by-Side: 1080/24p, 1080i (60 Hz),
720p (60 Hz)
Over-Under: 1080p (30 Hz), 1080/24p,
1080i (60 Hz), 720p (60 Hz)
TV
Rear of TV
