Sony Bravia KDL-75W850C User Manual

14
US
*
1
Signifies a BRAVIA Sync capable device.
*
2
The optical connection is only needed for A/V receivers that do not support ARC (Audio
Return Channel).
Set the speaker settings to audio out, press HOME, then select [Settings]  [Sound] 
[Speakers]  [Audio System].
Set the HDMI CEC settings on the TV and AV receiver to allow for system audio control for
ARC connections.
Showing HD BRAVIA® Sync™ Basic Connection
*
1
Side Panel
*
1
Blu-ray Disc
HD Cable Box or
HD Satellite Receiver
*
1
A/V Receiver
SAT (Dish)
Cable/
Antenna
*
2
Optical Connection
*
1
Rear of TV
Under Panel

Sony Bravia KDL-75W850C Specifications

General

Screen Type	led
Wall Mount	400mm x 300mm
Tuner	digital
Screen Size	74.5 inches, 75 inches
Refresh Rate	120hz
Closed Captioning	yes
HDR	no
Built-In Speakers	yes
Surround Sound	dolby digital plus, dolby pulse, surround sound
Speakers Output	20 watts
USB Ports	2
RF Antenna	yes
Network	built-in wi-fi
Headphones Output	yes
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	sony smart tv
Remote Control	standard
3D	yes
Power Consumption	250 kilowatt hours
Depth with Stand	13 inches
Height with Stand	40 inches
Width with Stand	66 inches
Net Weight with Stand	76.9 pounds
Depth without Stand	3.125 inches
Height without Stand	38.25 inches
Net Weight without Stand	74.3 pounds
