Section 1 OPERATION
1-4-6 BKDS-2031 Chromakey Board
General
Power requirements
+5 VDC 40.2 V
+3.3 VDC +40.2V
Power consumption: 10 W maximum
Temperature range
Storage: —20°C to +60°C (-4’F to +140°F)
Operation guaranteed: 5°C to 40°C (41 °F to 104°F)
Performance guaranteed: 10°C to 35°C (50 °F to 95 °F)
Dimensions (excluding projections)
320x20x160 mm (12 5/e x !3/16 x 6 3/8 inches) (w/h/d)
Mass: 1.3 kg
Input
Selectable from primary inputs
Input method
e Forforeground |
4:2:2 or 4:4:4 (using two serial digital inputs)
e Forbackground
4:2:2
Functions
Oversampling
Color modifucation (for foreground)
Exclusive mask generator
1-4-7 BKDS-2032 Chromakey Upgrade
Board
General
Power requirements
+5 VDC 40.2 V
+3.3 VDC 10.2 V
Power consumption: 13 W maximum
Temperature range
Storage: -20°C to +60°C (-4 °F to +140 “F)
Operation guaranteed: 5°C to 40°C (41°F to 104°F)
Performance guaranteed: 10°C to 35°C (50 °F to 95 °F)
Dimensions (excluding projections)
320x20x220 mm (12 7/8 x fis x 8 3/4 inches) (w/h/d)
Mass: 0.7 kg
