5-11
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DCR-HC51E/HC52/HC52E/HC53E/HC54/HC54E_L2
• Refer to page 5-1 for mark 0.
A-1438-781-A AV-125 BOARD, COMPLETE
**********************
< CONNECTOR >
CN401 1-779-330-51 CONNECTOR, FFC/FPC 12P
CN402 1-815-794-13 CONNECTOR (MULTIPLE) (A/V R)
< FERRITE BEAD >
FB401 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
FB402 1-500-238-11 BEAD, FERRITE (CHIP) (1608)
************************************************************
A-1438-759-A CD-735 BOARD, COMPLETE
**********************
(IC7101 is not included in CD-735 complete board.)
< CAPACITOR >
C7101 1-124-779-00 ELECT CHIP 10uF 20% 16V
C7103 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C7104 1-124-779-00 ELECT CHIP 10uF 20% 16V
C7105 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
* CN7101 1-818-045-51 CONNECTOR, FFC/FPC 14P
< IC >
IC7101 8-753-244-70 IC ICX610NKF-13 (CCD IMAGER)
(HC52/HC54)
IC7101 8-753-244-71 IC ICX611NKF-13 (CCD IMAGER)
(HC51E/HC52E/HC53E/HC54E)
< COIL >
L7101 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
* Q7101 6-551-873-01 TRANSISTOR 2SC3931G0LS0
< RESISTOR >
R7101 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
************************************************************
A-1438-782-A CF-111 BOARD, COMPLETE
**********************
(BT901 (LITHIUM STORAGE BATTERY) and SP901 (SPEAKER) are not
included in CF-111 complete board.)
< SPEAKER >
SP901 1-825-260-51 LOUD SPEAKER (1.6CM)
< BATTERY HOLDER >
0 BH801 1-756-615-41 HOLDER, BATTERY (Note 2)
< BATTERY >
0 BT901 1-756-134-12 BATTERY, STORAGE, LITHIUM (Note 2)
< CONNECTOR >
CN801 1-794-057-11 PIN, CONNECTOR (PC BOARD) 2P
* CN802 1-766-646-51 CONNECTOR, FFC/FPC 10P
< DIODE >
* D801 6-501-573-01 DIODE CL-271TLY-C-TS (CHG)
< RESISTOR >
R801 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R802 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
< SWITCH >
S801 1-786-157-31 TACTILE SWITCH (RESET)
S802 1-786-157-31 TACTILE SWITCH (DISP/BATT INFO)
S803 1-786-157-31 TACTILE SWITCH (EASY)
* S804 1-786-545-41 SWITCH, PUSH LEVER (S)
(PANEL OPEN/CLOSE)
S805 1-786-157-31 TACTILE SWITCH (BACKLIGHT)
************************************************************
(Not supplied) FP-031 FLEXIBLE BOARD
********************
(This flexible board is included in MD (N220) sub assy (S) A (A-1437-006-A).)
< DIODE >
D901 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T
(S REEL SENSOR)
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T
(T REEL SENSOR)
< CONNECTOR >
MIC902 1-818-576-11 PIN, CONNECTOR (WITH DETECTION)
(4 PIN CONNECTOR)
< TRANSISTOR >
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F
(TAPE END SENSOR)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F
(TAPE TOP SENSOR)
< SWITCH >
S901 1-786-448-22 SWITCH, PUSH (1 KEY) (CC DOWN)
************************************************************
(Not supplied) FP-032 FLEXIBLE BOARD
********************
(This flexible board with S903 is included in MD (N220) sub assy A (A-1437-006-A).)
************************************************************
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Note 1: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
Note 2: Replace the battery holder (BH801) together when
replacing the lithium storage battery (BT901) on the
CF-111 board. (The battery holder removed once can-
not be used again.)
When mounting these parts, mount new battery holder
first and attach new lithium storage battery next.
FP-032FP-031CF-111CD-735AV-125
To Next Page
