HBD-E770W
14
2-6. FRONT PANEL BLOCK
Note: Please prepare the thin wire (clip etc.).
2-7. BD DRIVE (BPX-5)
5 three screws
(BV3)
7 three screws
(BV3)
7 three screws
(BV3)
6 three ground plates (front)
2
9
3 three claws
3 claw
4 loading panel assy
(10EZ)
8 three claws
8 two claws
8 three claws
q; connector
(CN700)
qa front panel block
clip etc.
1
3 bracket L (MB foot)
6 sound sheet
7 BD drive (BPX-5)
4 four screws (BV3)
