HBD-E770W
16
2-10. MAIN BOARD
2-11. AUDIO BOARD
5 wire (flat type) (27 core)
(CN505)
6 wire (flat type) (15 core)
(CN508)
1 screw
(BV3)
3 bracket R
(MB foot)
2
4 connector
(CN904)
7 wire (flat type) (17 core)
(CN503)
8 wire (flat type) (15 core)
(CN702)
q; wire (flat type) (16 core)
(CN703)
9 wire (flat type) (18 core)
(CN701)
qa three screws
(BV3)
qd two screws
(BV3)
qd seven screws
(BV3)
qf MAIN board
qs heat sink
(S-master DDV)
6 three screws (BV3)
7 AUDIO board
3 bracket L
(MB foot)
1 screw (BV3)
2
4 connector
(CN17)
5 wire (flat type) (17 core)
(CN14)
