97
HBD-E770W
SECTION 7
ELECTRICAL PARTS LIST
A-1746-104-A AUDIO BOARD, COMPLETE
************************
< CAPACITOR >
C10 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C11 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C12 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C14 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C15 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C16 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C17 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C20 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C21 1-126-964-11 ELECT 10uF 20% 50V
C22 1-104-658-91 ELECT 100uF 20% 10V
C23 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C27 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C28 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C29 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C32 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C33 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C35 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C37 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C39 1-104-662-91 ELECT 22uF 20% 25V
C41 1-104-662-91 ELECT 22uF 20% 25V
C44 1-104-658-91 ELECT 100uF 20% 10V
C45 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C48 1-126-947-11 ELECT 47uF 20% 35V
C49 1-115-156-11 CERAMIC CHIP 1uF 10V
C50 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C53 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C54 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C62 1-126-947-11 ELECT 47uF 20% 35V
C63 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C66 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C67 1-115-156-11 CERAMIC CHIP 1uF 10V
C68 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C69 1-126-964-11 ELECT 10uF 20% 50V
C70 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN10 1-784-770-11 CONNECTOR, FFC 9P
CN14 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN17 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D10 6-500-848-01 DIODE MC2840-T112-1
D12 6-500-848-01 DIODE MC2840-T112-1
D15 6-501-728-01 DIODE MAZ8051G0LS0
< IC >
IC10 8-759-100-96 IC uPC4558G2
IC11 8-759-430-37 IC MC14052BDTR2
IC12 8-759-430-37 IC MC14052BDTR2
IC14 6-712-744-01 IC TK11190CSCL-G
< JACK >
J10 1-563-330-31 JACK (A.CAL MIC ECM-AC2)
J11 1-778-940-21 PHONO JACK 2P (AUDIO AUDIO IN)
< COIL >
L010 1-481-524-11 INDUCTOR 10uH
< TRANSISTOR >
Q10 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q13 6-551-690-01 TRANSISTOR RT3N11M-TP-1
Q14 8-729-028-96 TRANSISTOR DTC114EUA-T106
< RESISTOR >
R12 1-216-864-11 SHORT CHIP 0
R13 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R15 1-216-845-11 METAL CHIP 100K 5% 1/10W
R20 1-216-817-11 METAL CHIP 470 5% 1/10W
R21 1-216-864-11 SHORT CHIP 0
R22 1-216-837-11 METAL CHIP 22K 5% 1/10W
R23 1-216-809-11 METAL CHIP 100 5% 1/10W
R24 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-864-11 SHORT CHIP 0
R26 1-216-809-11 METAL CHIP 100 5% 1/10W
R27 1-216-864-11 SHORT CHIP 0
R28 1-216-821-11 METAL CHIP 1K 5% 1/10W
R29 1-216-837-11 METAL CHIP 22K 5% 1/10W
R30 1-216-833-11 METAL CHIP 10K 5% 1/10W
R32 1-216-833-11 METAL CHIP 10K 5% 1/10W
R34 1-216-835-11 METAL CHIP 15K 5% 1/10W
R35 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R36 1-216-864-11 SHORT CHIP 0
R37 1-216-857-11 METAL CHIP 1M 5% 1/10W
R42 1-216-864-11 SHORT CHIP 0
R43 1-216-864-11 SHORT CHIP 0
R44 1-216-837-11 METAL CHIP 22K 5% 1/10W
R45 1-216-837-11 METAL CHIP 22K 5% 1/10W
R46 1-216-841-11 METAL CHIP 47K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AUDIO
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
