Sony HCD-FR1 User Manual

3131
HCD-FR1/FR8/FR9
HCD-FR1/FR8/FR9
3-23. PRINTED WIRING BOARD — IO BOARD —
• See page 7 for Circuit Boards Location. :Uses unleaded solder.
TUNER
UNIT
DMB08
BOARD
CN003
(Page 13)
F
DMB08
BOARD
CN002
(Page 13)
E
IC603
IC602
IC605
3
1
2
4
OPTICAL
DIGITAL
IN
SURROUND
BACK
VIDEO
SAT
P B /C B
P R /C R
Y
VIDEO
S VIDEO
(DVD ONLY)
MONITOR
OUT
COMPONENT
VIDEO OUT
L R
IC201
IC606
12
A
B
C
D
E
F
34567
8 910
• Semiconductor
Location
Ref. No. Location
IC201 B-6
IC602 F-2
IC603 A-7
IC605 F-3
IC606 E-6
Q101 A-7
Q102 B-1
Q604 F-6
Q605 F-6
Q606 F-3
Q607 F-6
Ver 1.2
