Page #34 background image
3434
HCD-FR1/FR8/FR9
HCD-FR1/FR8/FR9
3-26. PRINTED WIRING BOARD — DDCON BOARD —
• See page 7 for Circuit Boards Location. :Uses unleaded solder.
IC802
O
FL
BOARD
CN803
(Page 36)
P
DISC KEY
BOARD
CN804
(Page 39)
14
15
D
DMB08
BOARD
CN005
(Page 13)
12
A
B
C
D
34567
• Semiconductor
Location
Ref. No.
Location
D810 C-5
D811 C-5
D813 C-5
D814 C-5
D815 C-3
IC802 A-2
Q802 C-6
