HCD-GX355/GX555/RG270/RG475/RG575
15
4
Remove the two solderings of motor.
3
MOTOR (LD) board
1
b
elt (loading)
5
l
oading motor assy (M751)
2
two
screws
(+BTTP (M2.6))
3-14. MOTOR (LD) BOARD
