Sony HCD-RG270 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
90
HCD-GX355/GX555/RG270/RG475/RG575
C503 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C504 1-104-662-91 ELECT 22uF 20% 25V
C505 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C506 1-104-665-11 ELECT 100uF 20% 25V
C507 1-126-967-11 ELECT 47uF 20% 50V
C508 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C509 1-128-563-11 ELECT 100uF 20% 100V
C510 1-128-582-11 ELECT 10uF 20% 100V
C511 1-128-582-11 ELECT 10uF 20% 100V
C512 1-136-165-00 FILM 0.1uF 5% 50V
C513 1-136-165-00 FILM 0.1uF 5% 50V
C514 1-126-948-11 ELECT 100uF 20% 35V
C516 1-126-964-11 ELECT 10uF 20% 50V
C517 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN501 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN502 1-564-509-11 PLUG, CONNECTOR 6P
< DIODE >
D501 8-719-083-82 DIODE UDZS-TE17-12B
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC501 6-600-091-01 IC STK404-130S
< JACK >
JK501 1-780-242-11 TERMINAL BOARD, PUSH (ANTENNA) 2P
(SUB WOOFER OUT, IMPEDANCE USE 6-16Ω)
< JUMPER RESISTOR >
JR501 1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q501 6-551-268-01 TRANSISTOR 2SC5625
Q502 8-729-600-22 TRANSISTOR 2SA1235-F
Q503 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q505 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q506 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R501 1-216-841-11 METAL CHIP 47K 5% 1/10W
R502 1-216-841-11 METAL CHIP 47K 5% 1/10W
R503 1-216-821-11 METAL CHIP 1K 5% 1/10W
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R505 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
0 R506 1-202-972-61 FUSIBLE 1 5% 1/4W F
0 R507 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
0 R508 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
0 R509 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R510 1-217-156-00 METAL 0.22 10% 5W F
0 R511 1-217-156-00 METAL 0.22 10% 5W F
R512 1-216-797-11 METAL CHIP 10 5% 1/10W
R513 1-216-821-11 METAL CHIP 1K 5% 1/10W
R514 1-216-837-11 METAL CHIP 22K 5% 1/10W
R515 1-216-841-11 METAL CHIP 47K 5% 1/10W
R516 1-216-813-11 METAL CHIP 220 5% 1/10W
R517 1-216-833-11 METAL CHIP 10K 5% 1/10W
R518 1-216-833-11 METAL CHIP 10K 5% 1/10W
R520 1-216-845-11 METAL CHIP 100K 5% 1/10W
R521 1-216-809-11 METAL CHIP 100 5% 1/10W
R522 1-216-809-11 METAL CHIP 100 5% 1/10W
R523 1-216-809-11 METAL CHIP 100 5% 1/10W
R524 1-216-841-11 METAL CHIP 47K 5% 1/10W
R525 1-216-797-11 METAL CHIP 10 5% 1/10W
R526 1-216-797-11 METAL CHIP 10 5% 1/10W
R527 1-216-797-11 METAL CHIP 10 5% 1/10W
R529 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R530 1-216-837-11 METAL CHIP 22K 5% 1/10W
R531 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R532 1-216-837-11 METAL CHIP 22K 5% 1/10W
R533 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R534 1-202-972-61 FUSIBLE 1 5% 1/4W F
< RELAY >
RY501 1-755-373-11 RELAY
************************************************************
1-687-669-12 SW BOARD
*********
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE)
(OPEN/CLOSE DETECT)
************************************************************
A-1094-068-A TRANSFORMER BOARD, COMPLETE (GX555)
A-1094-069-A TRANSFORMER BOARD, COMPLETE
(RG475: AEP, UK, EE, RU)
A-1094-070-A TRANSFORMER BOARD, COMPLETE (AUS)
A-1094-071-A TRANSFORMER BOARD, COMPLETE
(RG270: E2, E3, E51/RG475: E3, SP)
A-1094-074-A TRANSFORMER BOARD, COMPLETE (GX355)
A-1094-075-A TRANSFORMER BOARD, COMPLETE
(RG270: AEP, UK, EE, RU)
A-1094-076-A TRANSFORMER BOARD, COMPLETE (EA)
A-1094-077-A TRANSFORMER BOARD, COMPLETE
(RG270: MX)
A-1094-078-A TRANSFORMER BOARD, COMPLETE
(RG270: AR)
A-1094-096-A TRANSFORMER BOARD, COMPLETE
(RG575: E2, E51, SP)
A-1094-097-A TRANSFORMER BOARD, COMPLETE
(RG575: MX)
A-1094-098-A TRANSFORMER BOARD, COMPLETE
(RG575: AR)
******************************
1-533-233-31 FUSE HOLDER
< CAPACITOR >
C907 1-136-165-00 FILM 0.1uF 5% 50V
TRANSFORMERSWSUB WOOFER
Ver. 1.1
