HCD-X1
13
3-3. SIDE PANEL (L/R)
3
Remove the side panel (L)
in the direction of the arrow.
4
Remove the side panel (R)
in the direction of the arrow.
2
cover (rear)
1
five screws
(BVTP 3
×
8)
3-4. CASE (AL)
1
three screws
(BVTP 3
×
8)
2
case (AL)
1
screw
(BVTP 3
×
8)
1
screw
(BVTP 3
×
8
)
