HCD-X1
15
3-6. MAIN BOARD
3-7. D.C. FAN (M450), BACK PANEL SECTION
8
three screws
(BVTP 3
×
8)
8
screw
(BVTP 3
×
8)
8
screw
(BVTP 3
×
8)
1
wire (flat type) (9 core)
(AEP, UK, Russian and Singapore models),
wire (flat type) (11 core)
(US, Canadian models)
(CN502)
2
wire (flat type) (19 core)
(CN501)
7
connector
(CN507)
6
two saranet cushions
7
connector
(CN506)
7
connector
(CN5101)
9
MAIN board
3
wire (flat type) (11 core)
(CN504)
4
wire (flat type) (11 core)
(CN503)
5
wire (flat type) (21 core)
(CN506)
3
eight screws
(BVTP 3
×
8)
3
two screws
(BVTP 3
×
8
9
two screws
(P 3
×
14)
5
4
two screws
(supplied with
CN300)
3
screw
(BVTP 3
×
8)
1
wire (flat type) (28 core)
(US, Canadian models)
(CN5401)
2
wire (flat type) (12 core)
(US, Canadian models)
(CN5201)
7
wire (flat type) (17 core)
(AEP, UK and Russian models)
(CN903)
8
connector
(CN450)
6
wire (flat type) (13 core)
(CN902)
qs
back panel section
qs
screw
(BV 3)
qf
sheet (main)
qd
nylon rivet (DIA. 3.5)
q;
two nuts
(N3)
qa
D.C. fan
(M450)
