Sony HDCU5500 User Manual

67
<COLOR BAR>
V01
HFR CHANNEL
MARK
ON, OFF
<BAR CHARACTER>
V02
BAR CHARACTER Sets the character string to be displayed on each of
lines 1 to 16.
ALL CLEAR Clears all the character strings set for BAR
CHARACTER.
<CCU VIDEO>
V03
MONO COLOR ON, OFF Turns the MONO COLOR function ON/OFF.
PHASE 0 to 359, 0
Sets the MONO COLOR function hue adjustment.
SATURATION –99 to 99, 0
Sets the MONO COLOR function color level
adjustment.
<DOWNCONVERT>
V04
4K-HD
DOWNCONVERT
FILTER
1
, 2, 3, 4, 1(V:0.3), 1(V:0.6) Selects the type of filter for downconverting from 4K
video signals to HD signals.
Enabled when CAMERA FORMAT is set to UHD/
59.94P(4K/HDR) or UHD/50P(4K/HDR).
SD ASPECT SQUEEZE, EDGE CROP
,
LETTER BOX
Selects the aspect ratio for SD output.
NTSC SETUP 7.5
, 0 IRE Sets the NTSC signal setup level.
<MONITOR>
V05
CHARACTER LEVEL 1, 2, 3, 4, 5
Sets the brightness of text in menus, etc.
LEVEL GATE OFF
, 1&2, 1, 2, (---) Sets level gate display.
OFF: Level gate is not displayed.
1: Displays level gate 1.
2: Displays level gate 2.
1&2: Displays level gate 1 & 2.
(---): Displayed when a camera is not connected
(Display only).
Y-LEVEL1 MIN 0 to 108% 49
Sets the minimum detection level for level gate 1
display.
MAX 0 to 108% 61
Sets the maximum detection levels for level gate 1
display.
LEVEL –99 to 99 –25
Sets the zebra display level to be added to the
detection area.
Y-LEVEL2 MIN 0 to 108% 74
Sets the minimum detection level for level gate 2
display.
MAX 0 to 108% 108
Sets the maximum detection levels for level gate 2
display.
LEVEL –99 to 99 –25
Sets the zebra display level to be added to the
detection area.
GATE MARKER OFF
, ON, (---) Sets the display of the gate signal detected by the
camera.
OFF: Gate signal is not displayed.
ON: Displays zebra in the area (skin gate, etc.)
detected by the camera.
(---): Displayed when a camera is not connected
(Display only).
LEVEL –99 to 99 0
Sets the zebra display level to be added to the
detection area.
ASPECT MARKER OFF
, ON Sets aspect marker display.
SELECT 4:3
, 13:9, 14:9, EU VISTA, VISTA,
CINEMA, FOLLOW DC
Selects the marker type.
MODULATION ON/
OFF
OFF
, ON Sets the mask function for outside the marker frame.
MODULATION
LEVEL
–99 to 99 0
Sets the mask level.
VIDEO/MONITOR
Page name
Page No.
Item Set value Description
