2-3
HDR-CX11E/CX12/CX12E_L2
2-2. DISASSEMBLY
2-2-1. OVERALL SECTION
Follow the disassembly in the numerical order given.
1 LCD Panel Section (1-1 to 1-15)
2 Front Panel Section (2-1 to 2-10)
HELP
HELP
EXPLODED VIEW
HARDWARE LIST
1-2
(#1/#14)
1-10
(#2)
1-9
(#2)
1-11 (#2)
1-8
(#2)
1-6
(#2)
1-4
(Claw)
1-5
1-3
1-1
(Open)
1-7
(Open)
1-14
1-15
1 LCD Panel
Section
(See Page 2-4)
2 Front Panel
Section
2-1 (#2/#10) 2-7 (#2)
2-8 (#2)
2-9
(#2)
2-10
2-4
2-6
2-5
2-2
(Claw)
2-3
HELP01
1-12 (#2)
1-13
(Claw)
Main Body Section
(See Page 2-6)
