5-12
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
HDR-CX11E/CX12/CX12E_L2
A-1553-322-A CK-203 BOARD, COMPLETE
**********************
< CONNECTOR >
CN6001 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
CN6002 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN6003 1-816-926-11 CONNECTOR, BOARD TO BOARD 40P
* CN6004 1-816-650-51 FFC/FPC CONNECTOR (LIF) 24P
< DIODE >
D6001 6-500-817-01 DIODE SML-512UWT86 (MS ACCESS)
< RESISTOR >
R6001 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6002 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R6003 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6004 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
< SWITCH >
S6001 1-771-138-21 SWITCH, KEY BOARD (DISP/BATT INFO)
S6002 1-771-731-11 SWITCH, SLIDE (NIGHTSHOT)
S6003 1-771-138-21 SWITCH, KEY BOARD (RESET)
S6004 1-771-138-21 SWITCH, KEY BOARD (EASY)
S6005 1-771-138-21 SWITCH, KEY BOARD (PLAY)
S6006 1-771-138-21 SWITCH, KEY BOARD (BACK LIGHT)
S6007 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
************************************************************
CK-203
Electrical parts list of the CM-094 is not
shown.
Pages 5-13 is not shown.
