2-7
HDR-TG1/TG1E/TG3E_L2
EXPLODED VIEW
HARDWARE LIST
2-2-5. CABINET (R) SECTION
Follow the disassembly in the numerical order given.
1 JK Holder Block (1-1 to 1-5)
2 Capacitor Block (2-1 to 2-2)
3 LCD Panel Block (3-1 to 3-13)
1-2 (#2)
1-3
(#2)
1-1
(#14)
1-4
1-5
1 JK Holder Block
2 Capacitor Block
2-2
(#2)
2-1
3 LCD Panel Block
3-1 (#14)
3-5
(#14)
3-2
3-3
3-4
3-6
3-7
3-8
3-9
3-10 (#14)
3-12 (#14)
3-11
3-13
