Sony HT-S100F User Manual

31
GB
Specifications
Amplifier section
POWER OUTPUT (rated)
Front woofer L + Front woofer R: 22 W
+ 22 W (at 8 ohms, 1 kHz, 1% THD)
Front tweeter L + Front tweeter R: 22 W
+ 22 W (at 8 ohms, 10 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/R woofer blocks: 30 W (per
channel at 8 ohms, 1 kHz)
Front L/R tweeter blocks: 30 W (per
channel at 8 ohms, 10 kHz)
Audio Inputs
TV IN (OPTICAL)
USB
HDMI OUT (TV (ARC))
TV Display Output (USB display)
HDMI OUT (TV (ARC))
USB section
(USB) port:
Type A (For connecting USB memory)
BLUETOOTH section
Communication system
BLUETOOTH Specification version 4.2
Output
BLUETOOTH Specification Power
Class 1
Maximum communication range
Line of sight approx. 10 m
1)
Frequency band
2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Maximum output power
< 10.0 dBm
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP (Audio Video Remote Control
Profile)
Supported Codec
3)
SBC
4)
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency
32 kHz, 44.1 kHz, 48 kHz)
1)
The actual range will vary depending on
factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless phone use, reception
sensitivity, the operating system,
software applications, etc.
2)
BLUETOOTH standard profiles indicate
the purpose of BLUETOOTH
communication between devices.
3)
Codec: Audio signal compression and
conversion format
4)
Abbreviation for Subband Codec
Front L/Front R speaker block section
Speaker system
2-way speaker system, Bass reflex
Speaker
Woofer: 48 mm × 90 mm cone type
Tweeter: 25 mm balanced dome type
General
Power requirements
220 V - 240 V AC, 50 Hz/60 Hz
Power consumption
On: 30 W
Standby mode: 0.5 W or less (Power
Saving mode)
(When Control for HDMI function and
BLUETOOTH Standby mode are set to
off)
Standby mode: 2 W or less
(When Control for HDMI function is set
to on and/or BLUETOOTH Standby
mode is set to on)
Dimensions* (approx.) (w/h/d)
900 mm × 64 mm × 90 mm
* Including projection portion
Mass (approx.)
2.4 kg
Design and specifications are subject to
change without notice.
Additional Information

Sony HT-S100F Specifications

General

Output power	120 W
Docking connector type	-
USB port	Yes
Bluetooth version	4.2
Connectivity technology	Wireless
Near Field Communication (NFC)	No
Audio decoders	Dolby Digital
RMS rated power	- W
Audio output channels	2.0 channels
Product color	Black
Audio formats supported	MP3, WAV, WMA
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Cables included	AC

Weight and Dimensions

Depth	64 mm
Width	900 mm
Height	88 mm
Soundbar weight	2400 g
