1-8. Writing/Rewriting the PLD Data
This section describes how to upgrade the PLD version of each board using the PLD download tool.
Equipment required
. A personal computer equipped with the parallel port (For the target OS, refer to the Operation Manual
supplied with the PLD Download Tool.)
. PLD Download Tool (J-7120-140-A)
Connection
1. Connect the PLD Download Tool to the parallel port of the personal computer.
2. Connect the cable (8-pin connector) coming from the PLD Download Tool to the following
connectors on the target boards.
Target board (Model Name) Ref. No. Project file No.
SW-1091 board (MKS-8080) CN102 E_000_001_33_xx
SW-1084 board (MKS-8082) CN110 E_000_001_34_xx
n
No setup is required in each board.
Downloading
1. Start up the PLD Download Tool Software on the personal computer. After reading data for
upgrading the PLD version, write the data and confirm that is correctly written.
n
For details of the operation, refer to the Operation Manual of the PLD Download Tool.
2. Upon completion of downloading, turn off the main power.
