2-1
BDP-BX38/S280/S380/S383
SECTION 2
DISASSEMBLY
 This set can be disassembled in the order shown below.
Note: Follow the disassembly procedure in the numerical order given.
2-2. UPPER CASE
tapping screw
(tightening torque = 5 to 6 NJIFP
1 Tapping
screw
(tightening torque =5 to 6
NJIFP
2
Three tapping screws
(tightening torque =
5 to6
NJIFP
3
2-1. DISASSEMBLY FLOW
2-2. UPPER CASE
3DJH
2-3. TRAY COVER ASSY
3DJH
2-8. SWITCHING REGULATOR
3DJH
2-7.
FRONT PANEL ASSY
3DJH
2-5. REAR PANEL
3DJH
2-6. MB-138 BOARD
3DJH
2-4.
BD DRIVE
3DJH
SET
Upper case
FL-203 & IF-170 boards
1
