Sony RMT-B109A - Front Panel and Board Removal

2-2
8
4
2
One screws
(tightening torque = 6 to 7 kgf•cm)
Front Panel
3
Harness (FLM-001)
CN331
FL-203 Board
2-4.
FRONT PANEL ASSY, FL-203 AND IF-170 BOARD
BDP-BX38/S280/S380/S383
2-3. TRAY COVER ASSY
tray
3 Tray cover assy
2
5
Eight hook
1
7
Two screws +BV3 (3-CR)
(tightening torque = 6 to 7 kgf•cm)
1 Insert a clip in the hole of a drive
to
open a tray.
IF-170 Board
9
Light guide
cover
6
+BV3 (3-CR)
One screws
(tightening torque = 6 to 7 kgf•cm)
+BV3 (3-CR)
Except BDP-S280
