2-4. FR-316 BOARD
FR-316 board
4
One screws+BV3(3-CR)
1
2-4
2-5. SWITCHING REGULATOR
Switching regulator
flexible flat
3
3 harness
(CN101)
6
BDP-BX18/S185/S186
cable (FIM-032)
(CN701)
4 harness PM-168
(CN201)
Two screws +BV3(3-CR)
5
PS insulator
2
USB shield case
2
ESD Shield
1
