Sony SA-32SE1 User Manual

17
GB
Troubleshooting/Specifications
The STANDBY indicator flashes.
• Turn off the unit and unplug the AC power
cord (mains lead) immediately.
• Remove anything that is blocking the
ventilation hole.
If the unit still does not operate
properly after performing the
above measures, reset the unit
as follows:
Use the button on the unit for the operation.
1 Press ?/1 to turn on the unit.
2 Hold down ?/1 for 5 seconds.
STANDBY indicator flashes 3 times and
the unit is reset to the default settings.
Specifications
Amplifier section
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
(FTC)
(USA model only)
L + R With 8 ohm loads, both
channels driven, from 300
– 20,000 Hz; rated 14 watts
per channel minimum
RMS power, with no more
than 1% total harmonic
distortion from 250
milliwatts to rated output.
POWER OUTPUT (reference)
L / R 20 W (per channel at
8 ohms, 1 kHz)
(China model only)
POWER OUTPUT (rated)
(Measured under MOVIE sound field)
L + R 9.5 W + 9.5 W
(at 8 ohms, 1 kHz,
1% THD)
(Other models)
POWER OUTPUT (rated)
L + R 16 W + 16 W
(at 8 ohms, 1 kHz,
1% THD)
POWER OUTPUT (reference)
L / R 20 W (per channel at
8 ohms, 1 kHz, 10% THD)
OTHER
continued

Sony SA-32SE1 Specifications

General

Tweeter	Yes
Speaker type	3-way
Speaker position	Front
Tweeter diameter	65 mm
Number of drivers	4
Speaker placement	Wall-mountable
Audio output channels	2.0 channels
Number of tweeter drivers	2
Product color	Black
Volume control	Digital
Recommended usage	-
Impedance	8 Ω
Frequency range	20 - 20000 Hz
RMS rated power	40 W
Total Harmonic Distortion (THD)	10 %
Number of products included	1 pc(s)
Connectivity technology	Wired
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Package depth	125 mm
Package width	815 mm
Package height	156 mm
Package weight	3000 g

Weight and Dimensions

Depth	76.7 mm
Width	754 mm
Height	80 mm
Weight	1900 g
