Sony SA-32SE1 User Manual

7
GB
Supplied accessories/Guide to parts and controls
Guide to parts and controls
This manual mainly explains operations using the buttons on the remote control, but the same
operations can also be performed using the buttons on the unit having the same or similar names.
Unit
Remote control (RM-ANU102)
A ?/1 (POWER) button
B SOUND FIELD button
Selects the sound field (page 14).
Unit: Each time you press the button, the sound
field changes cyclically as follows:
STANDARD t MOVIE t GAME/VOICE
t STANDARD t ...
C Unit: 2 +*/– button
Remote control: VOL 2 +/– button
Adjusts the volume.
* The 2 + button on the unit has tactile dots. Use the
tactile dots as references when operating the unit.
D Remote control sensor
Receives signals from remote control.
1
2
3
564
9
8
7
3
2
1
continued

Sony SA-32SE1 Specifications

General

Tweeter	Yes
Speaker type	3-way
Speaker position	Front
Tweeter diameter	65 mm
Number of drivers	4
Speaker placement	Wall-mountable
Audio output channels	2.0 channels
Number of tweeter drivers	2
Product color	Black
Volume control	Digital
Recommended usage	-
Impedance	8 Ω
Frequency range	20 - 20000 Hz
RMS rated power	40 W
Total Harmonic Distortion (THD)	10 %
Number of products included	1 pc(s)
Connectivity technology	Wired
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Package depth	125 mm
Package width	815 mm
Package height	156 mm
Package weight	3000 g

Weight and Dimensions

Depth	76.7 mm
Width	754 mm
Height	80 mm
Weight	1900 g
