Sony SA-NS300 User Manual

17
GB
Network Connections
Your computer must be connected to the
wireless LAN router/access point in advance.
Write down the SSID of your wireless LAN
router/access point.
Refer to the operating instructions of the
access point.
1 Check whether your computer
and wireless LAN router/
access point are turned on.
2 Connect the unit and the
wireless LAN router/access
point using a network (LAN)
cable.
3 Turn the unit on.
4 Click [My Network] or [Network]
t [SA-NS300].
The [Sony Network Device Setting]
screen appears.
Notes
• Install the UPnP service in advance if you are
using Windows XP (page 28).
• Refer to “Setting Screen on the Browser”
(page 27) for details on the display of [My
Network] or [Network].
• Check your set-up of the firewall of the
security software if you cannot find
[SA-NS300] or the browser does not open
even if you double-click [SA-NS300] on
screen of your computer.
• Restart your computer if you cannot find
[SA-NS300].
5 Select the desired language
when the “Language Setup”
screen appears.
6 Select [Network Settings] from
the menu.
7 Enter the SSID of your access
point.
Enter the SSID. Refer to the memo that
you wrote for this information.
Option 3: PIN method
SSID
Network
(LAN) cable

Sony SA-NS300 Specifications

General

Tweeter	-
Speaker position	Front
Number of drivers	1
Speaker enclosure	Reflex
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Bass reflex	Yes
Product color	Black
Recommended usage	Universal
Frequency range	100 - 20000 Hz
RMS rated power	- W
Type	Portable speakers
Equalizer	No
Connectivity technology	Wireless
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	123 mm
Width	141 mm
Weight	470 g
