9
SA-WMS145/WMSP50
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-688-810-11 CONTROL BOARD
***************
< CAPACITOR >
C801 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNP801 1-564-519-11 PLUG, CONNECTOR 4P
< VARIABLE RESISTOR >
RV801 1-225-826-11 RES, VAR, CARBON 20K (LEVEL)
*************************************************************
1-688-813-11 INPUT BOARD
************
< CAPACITOR >
C101 1-128-813-11 CERAMIC 220PF 5% 50V
C201 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN101 1-506-944-11 PIN, CONNECTOR 2P
< JACK >
J101 1-815-025-11 JACK, PIN 1P (INPUT)
< RESISTOR >
R110 1-249-441-11 CARBON 100K 5% 1/4W
R202 1-249-417-11 CARBON 1K 5% 1/4W
*************************************************************
1-688-812-11 LED BOARD
**********
< CONNECTOR >
* CN901 1-564-517-11 PLUG, CONNECTOR 2P
< DIODE >
D901 8-719-057-10 LED LNJ301MPUJAB (POWER)
*************************************************************
A-4734-911-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C203 1-136-165-00 FILM 0.1uF 5% 50V
C204 1-136-165-00 FILM 0.1uF 5% 50V
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-131-679-31 FILM 0.01uF 5% 50V
C208 1-131-696-11 FILM 0.22uF 5% 50V
C209 1-128-813-11 CERAMIC 220PF 5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-128-813-11 CERAMIC 220PF 5% 50V
C301 1-128-813-11 CERAMIC 220PF 5% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-126-968-11 ELECT 100uF 20% 50V
C305 1-126-968-11 ELECT 100uF 20% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-126-967-11 ELECT 47uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-136-165-00 FILM 0.1uF 5% 50V
C310 1-136-165-00 FILM 0.1uF 5% 50V
C311 1-162-199-31 CERAMIC 10PF 5% 50V
C312 1-128-813-11 CERAMIC 220PF 5% 50V
C313 1-128-813-11 CERAMIC 220PF 5% 50V
C401 1-136-165-00 FILM 0.1uF 5% 50V
C402 1-136-165-00 FILM 0.1uF 5% 50V
C403 1-104-482-11 ELECT 4700uF 20% 63V
C404 1-104-482-11 ELECT 4700uF 20% 63V
C405 1-126-968-11 ELECT 100uF 20% 50V
C406 1-126-968-11 ELECT 100uF 20% 50V
C407 1-126-971-11 ELECT 470uF 20% 50V
C408 1-126-971-11 ELECT 470uF 20% 50V
C409 1-136-165-00 FILM 0.1uF 5% 50V
C410 1-136-165-00 FILM 0.1uF 5% 50V
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-126-949-11 ELECT 220uF 20% 35V
C503 1-126-934-11 ELECT 220uF 20% 10V
C601 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN202 1-506-944-11 PIN, CONNECTOR 2P
CN204 1-564-505-11 PLUG, CONNECTOR 2P
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
MAIN
INPUTCONTROL
LED
