11
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-VE522/VE525/WM525/SS-MS525/V521
1-680-788-11 LED BOARD
*********
< CONNECTOR >
CN801 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D801 8-719-028-30 DIODE SPR-39MVWF
*********************************************************************
1-680-786-11 POWER BOARD
*************
< CAPACITOR >
C401 1-104-664-11 ELECT 47uF 20.00% 25V
< CONNECTOR >
* CN401 1-564-243-11 PIN, CONNECTOR 6P
< TRANSISTOR >
Q401 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q402 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q403 8-749-010-25 IC MN2488-OPY-M
Q404 8-749-010-26 IC MP1620-OPY-M
< RESISTOR >
R401 1-247-871-91 CARBON 47K 5% 1/4W
R402 1-247-839-91 CARBON 2.2K 5% 1/4W
0 R403 1-249-414-11 CARBON 560 5% 1/4W F
0 R404 1-249-408-11 CARBON 180 5% 1/4W F
0 R405 1-249-408-11 CARBON 180 5% 1/4W F
0 R406 1-217-151-00 METAL 0.22 10% 2W
0 R407 1-217-151-00 METAL 0.22 10% 2W
*********************************************************************
1-680-787-11 POWER SWITCH BOARD
*******************
< CAPACITOR >
0 C1 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
* CN1 1-695-044-11 PIN, CONNECTOR 2P
< SWITCH >
S1 1-554-920-61 SWITCH, PUSH (AC POWER)(1 KEY)
*********************************************************************
MISCELLANEOUS
*************
SP901 1-529-296-11 SPEAKER (20CM)
0 T501 1-435-999-11 TRANSFORMER, POWER (US,CND,MX)
0 T501 1-437-219-11 TRANSFORMER, POWER (SP)
0 T501 1-437-246-11 TRANSFORMER, POWER (AEP,UK)
0 T601 1-435-993-11 TRANSFORMER, POWER (US,CND,MX)
0 T601 1-435-994-11 TRANSFORMER, POWER (AEP,UK)
0 T601 1-435-995-11 TRANSFORMER, POWER (SP)
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-569-008-21 ADAPTOR, CONVERSION 2P
(SA-VE522/VE525)(SP)
1-769-329-21 CORD, CONNECTION
(SA-VE522/VE525)(PIN-PIN)
1-770-019-12 ADAPTOR CONVERSION PLUG 3P (UK)
1-790-503-11 CORD, SPEAKER (10m)(SA-VE525)
1-790-503-11 CORD, SPEAKER (10m)(SS-V521)
1-790-503-21 CORD, SPEAKER (2.5m)(SA-VE522/VE525)
1-790-503-31 CORD, SPEAKER (3.5m)(SA-VE522/VE525)
3-701-443-21 WASHER, 5 DIA. (SA-VE522/VE525)
4-233-674-11 MANUAL, INSTRUCTION
(SA-VE522/VE525)(CND,UK,US)
(ENGLISH,FRENCH)
4-233-674-21 MANUAL, INSTRUCTION
(SA-VE522/VE525)(AEP)(ENGLISH,FRENCH,
GERMAN,ITALIAN)
4-233-674-31 MANUAL, INSTRUCTION
(SA-VE522/VE525)(AEP)(DUTCH,SPANISH,
SWEDISH,POLISH)
4-233-674-41 MANUAL, INSTRUCTION
(SA-VE522/VE525)(AEP)(PORTUGUESE,
DANISH,FINNISH,RUSSIAN)
4-233-674-51 MANUAL, INSTRUCTION
(SA-VE522/VE525)(MX,SP)(ENGLISH,
FRENCH,SPANISH,CHINESE)
4-972-322-01 FOOT (Y)(SA-VE522/VE525)
4-972-322-01 FOOT (Y)(SS-V521)
4-233-678-11 MANUAL, INSTRUCTION
(SS-V521)(US,CND)(ENGLISH,FRENCH)
4-233-678-21 MANUAL, INSTRUCTION
(SS-V521)(AEP)(ENGLISH,FRENCH,
GERMAN,ITALIAN)
4-233-678-31 MANUAL, INSTRUCTION
(SS-V521)(AEP)(DUTCH,SPANISH,
SWEDISH,POLISH)
4-233-678-41 MANUAL, INSTRUCTION
(SS-V521)(AEP)(PORTUGUESE,
DANISH,FINNISH,RUSSIAN)
4-233-678-51 MANUAL, INSTRUCTION
(SS-V521)(E)(ENGLISH,FRENCH,
SPANISH,CHINESE)
X-4953-333-1 STAND ASSY (SA-VE522/VE525)
**************************************************************
**********
HARDWARE LIST
**********
#1 7-685-664-79 SCREW +P 4X20 TYPE1
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-662-79 SCREW +BVTP 4X14 TYPE2 N-S
#4 7-685-660-19 SCREW +BVTP 4X10 TYPE2 N-S
#5 7-685-647-79 SCREW +P 3X10 TYPE2 NON-SLIT
The components identified by mark 0 or
dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.
LED
POWER POWER SWITCH
