8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-VE522/VE525/WM525/SS-MS525/V521
SECTION 4
ELECTRICAL PARTS LIST
1-680-789-11 AUTO POWER BOARD
******************
1-533-217- HOLDER, FUSE
< CAPACITOR >
0 C2 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
0 C3 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
(CND,AEP,UK,US,MX)
0 C4 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
(SP)
0 C5 1-113-924-11 CERAMIC 0.0047uF 20.00%250V
C601 1-104-666-11 ELECT 220uF 20.00% 25V
C602 1-104-666-11 ELECT 220uF 20.00% 25V
C603 1-126-964-11 ELECT 10uF 20.00% 50V
C604 1-126-964-11 ELECT 10uF 20.00% 50V
C605 1-126-964-11 ELECT 10uF 20.00% 50V
C606 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN601 1-564-505-11 PLUG, CONNECTOR 2P
CN602 1-564-505-11 PLUG, CONNECTOR 2P
* CN604 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
* CN605 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D601 8-719-974-59 DIODE 1SR139-100
D602 8-719-974-59 DIODE 1SR139-100
D603 8-719-974-59 DIODE 1SR139-100
D604 8-719-974-59 DIODE 1SR139-100
D605 8-719-921-88 DIODE MTZJ-13B
D606 8-719-921-88 DIODE MTZJ-13B
D607 8-719-911-19 DIODE 1SS119-25 (CND,AEP,UK,US,MX)
D608 8-719-911-19 DIODE 1SS119-25 (SP)
<FUSE>
0 F601 1-532-744-11 FUSE 2.5A/125V (US,CND,MX)
0 F601 1-532-463-11 FUSE 1A/250V (AEP,UK)
0 F601 1-532-215-00 FUSE TIME-LAG T800mAL/250V (SP)
0 F602 1-532-259-00 FUSE TIME-LAG T1.6AL/250V (SP)
< TRANSISTOR >
Q601 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q602 8-729-173-38 TRANSISTOR 2SA733-K
< RESISTOR >
R601 1-247-843-11 CARBON 3.3K 5% 1/4W
R602 1-247-843-11 CARBON 3.3K 5% 1/4W
< RELAY >
RY601 1-755-276-11 RELAY, POWER (CND,AEP,UK,US,MX)
RY602 1-755-276-11 RELAY, POWER (SP)
< SWITCH >
0 S601 1-771-474-11 SWITCH, POWER
(VOLTAGE SELECTOR)(SP,MX)
**************************************************************
1-680-785-11 CONTROL BOARD
***************
< CAPACITOR >
C201 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C202 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C203 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C204 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C205 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C206 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C207 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C208 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C209 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C210 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C211 1-126-964-11 ELECT 10uF 20.00% 50V
C212 1-126-964-11 ELECT 10uF 20.00% 50V
C213 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C214 1-136-165-00 MYLAR 0.1uF 5.00% 50V
< CONNECTOR >
* CN201 1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
< IC >
IC201 8-759-145-58 IC BA4558
IC202 8-759-145-58 IC BA4558
IC203 8-759-145-58 IC BA4558
IC204 8-759-145-58 IC BA4558
< RESISTOR >
R201 1-247-831-91 CARBON 1K 5% 1/4W
R202 1-247-855-91 CARBON 10K 5% 1/4W
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
SP : Singapore model
MX : Mexican model
When indicating parts by reference number,
please include the board name.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
CONTROLAUTO POWER
