Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
11
SA-WMSP2/WMSP4
SWITCH
1-684-033-11 POWER TRANS BOARD
*******************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
0 C2 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR 2P
* CN2 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
0 S2 1-762-753-11 SWITCH, VOL-SEL (VOLTAGE SELECTOR) (E)
**************************************************************
1-684-030-11 SWITCH BOARD
*************
< CAPACITOR >
0 C901 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
CN3 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
0 S901 1-786-325-11 SWITCH, POWER (POWER)
**************************************************************
POWER TRANS
MISCELLANEOUS
***************
0 15 1-769-744-11 CORD, POWER (UK,AEP,MY,SP)
0 15 1-783-528-11 CORD, POWER (TRACKING) (E)
0 15 1-783-820-11 CORD, POWER (US,CND,MX)
0 15 1-783-941-12 CORD, POWER (AR)
0 F901 1-532-463-51 FUSE (T1AL/250V) (WMSP4:AR,UK,AEP,MY,SP)
0 F901 1-532-464-31 FUSE (T2.5AL/250V) (WMSP2:E/WMSP4:E)
0 F901 1-532-500-31 FUSE (T0.63AL/250V) (WMSP2:UK,AEP,MY,SP)
0 F901 1-532-744-11 FUSE, GLASS TUBE (2.5A/125V)
(WMSP2:US,CND/WMSP4:US,CND,MX)
0 F902 1-532-502-51 FUSE (T1.25AL/250V) (WMSP2:E/WMSP4:E)
SP1 1-529-995-11 SPEAKER (20cm) (WMSP2)
SP1 1-825-004-11 LOUD SPEAKER (WMSP4)
0 T1 1-437-657-11 POWER TRANSFORMER (WMSP2:E)
0 T1 1-437-658-11 POWER TRANSFORMER
(WMSP2:UK,AEP,MY,SP)
0 T1 1-437-659-11 POWER TRANSFORMER (WMSP2:US,CND)
0 T1 1-437-660-11 POWER TRANSFORMER
(WMSP4:AR,UK,AEP,MY,SP)
0 T1 1-437-661-11 POWER TRANSFORMER (WMSP4:US,CND,MX)
0 T1 1-437-662-11 POWER TRANSFORMER (WMSP4:E)
**************************************************************
ACCESSORIES
************
0 1-569-008-21 ADAPTOR, CONVERSION 2P (E)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#2 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#3 7-685-881-09 SCREW +BVTT 4X8 (S)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
