SERVICE MANUAL
Sony CONFIDENTIAL
For Authorized Servicer
SPECIFICATIONS
HT-S350/SD35
SOUND BAR
SA-S350/SD35
ACTIVE SPEAKER SYSTEM
US Model
AEP Model
UK Model
HT-S350/SD35/SA-S350/SD35
Canadian Model
HT-S350/SA-S350
Ver. 1.0 2019.02
HT-S350/SD35
SA-S350/SD35
• All of the units included in the HT-S350 (SA-
S350/SA-WS350/Remote control) or HT-SD35
(SA-SD35/SA-WSD35/Remote control) are re-
quired to confi rming operation of this unit. Check
in advance that you have all of the units.
COMPONENT MODEL NAME
HT-S350 HT-SD35
Bar Speaker (Active Speaker System) SA-S350 SA-SD35
Subwoofer (Active Subwoofer) SA-WS350 SA-WSD35
• Please refer to service manual separately issued for Subwoofer.
Photo: SA-S350
Amplifier section
U.S. models:
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(FTC)
Front L + Front R:
With 4 ohms loads, both channels
driven, from 200 - 20,000 Hz; rated
18 W per channel minimum RMS
power, with no more than 1% total
harmonic distortion from 250 mW to
rated output.
POWER OUTPUT (reference)
Front L/Front R speaker: 85 W (per
channel at 4 ohms, 1 kHz)
CND, AEP, UK models:
POWER OUTPUT (rated)
Front L + Front R: 45 W + 45 W (at
4 ohms, 1 kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R speaker: 85 W (per
channel at 4 ohms, 1 kHz)
Inputs
TV IN (OPTICAL)
Outputs
HDMI OUT (TV (ARC))
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency
32 kHz, 44.1 kHz, 48 kHz)
1)
The actual range will vary depending on
factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless phone use, reception
sensitivity, the operating system,
software applications, etc.
2)
BLUETOOTH standard profiles indicate
the purpose of BLUETOOTH
communication between devices.
3)
Codec: Audio signal compression and
conversion format
4)
Abbreviation for Subband Codec
Front L/Front R speaker block section
Speaker system
2 Speaker System
Speaker
Front L/Front R speaker: 52 mm ×
90mm (2 1/8in × 3 5/8in) cone type,
4Ω
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP (Audio Video Remote Control
Profile)
Supported Codec
3)
SBC
4)
BLUETOOTH section
Communication system
BLUETOOTH Specification version 5.0
Output
BLUETOOTH Specification Power
Class 1
Maximum communication range
Line of sight approx. 25 m
1)
Frequency band
2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Maximum output power (AEP, UK)
≤ 6 dBm
– Continued on next page –
