SDM-S71(E) 2-5
2-5. TIMING SPECIFICATION
PRESET MODE MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7 MODE 8
SIGNAL MODE VESA 60Hz MAC 13” VESA 75Hz VESA 85Hz VESA 70Hz VESA 60Hz VESA 75Hz VESA 85Hz
RESOLUTION 640 X 480 640 X 480 640 X 480 640 X 480 720 X 400 800 X 600 800 X 600 800 X 600
DOT CLOCK 25.175 MHz 30.240 MHz 31.500 MHz 36.000 MHz 28.350 MHz 40.000 MHz 49.500 MHz 56.250 MHz
HORIZONTAL usec usec usec usec usec usec usec usec
H. TOATL 31.778 28.571 26.667 23.111 31.746 26.400 21.333 18.631
H. SYNC 3.813 2.116 2.032 1.556 2.540 3.200 1.616 1.138
H. BP 1.907 3.175 3.810 2.222 3.175 2.200 3.232 2.702
H. ACTIV 25.422 21.164 20.317 17.778 25.397 20.000 16.162 14.222
VERTICAL msec msec
msec
msec
msec
msec
msec
msec
V. TOTAL 16.683 15.000 13.333 11.764 14.254 16.579 13.333 11.756
V. SYNC 0.064 0.086 0.080 0.069 0.095 0.106 0.064 0.056
V. BP 1.049 1.114 0.427 0.578 1.079 0.607 0.448 0.503
V. ACTIV 15.253 13.714 12.800 11.093 12.698 15.840 12.800 11.179
H/V POLARITY N/N N/N N/N N/N N/P P/P P/P P/P
PRESET MODE MODE 9 MODE 10 MODE 11 MODE 12 MODE 13
SIGNAL MODE PMAC 16” VESA 60Hz VESA 70Hz VESA 75Hz 75Hz
RESOLUTION 832 X 624 1024 X 768 1024 X 768 1024 X 768 1024 X 768
DOT CLOCK 57.285 MHz 65.000 MHz 75.000 MHz 78.750 MHz 94.500 MHz
HORIZONTAL usec usec usec usec usec
H. TOATL 20.110 20.677 17.707 16.660 14.561
H. SYNC 1.117 2.092 1.813 1.219 1.016
H. BP 3.910 2.462 1.920 2.235 2.201
H. ACTIV 14.524 15.754 13.653 13.003 10.836
VERTICAL msec msec
msec
msec
msec
V. TOTAL 13.413 16.666 14.272 13.328 11.765
V. SYNC 0.060 0.124 0.106 0.050 0.044
V. BP 0.744 0.600 0.513 0.466 0.524
V. ACTIV 12.549 15.880 13.599 12.795 11.183
H/V POLARITY N/N N/N N/N P/P P/P
MODE 14 MODE 15 MODE 16
PMAC 19” MAC WS
1024 X 768 1152 X 870 1152 X 900
80.000 MHz 100.000 MHz 92.940 MHz
usec usec usec
16.600 14.560 16.182
1.200 1.280 1.377
2.200 1.440 2.087
12.800 11.520 12.395
msec
msec
msec
13.346 13.322 15.163
0.050 0.048 0.065
0.498 0.568 0.502
12.749 12.667 14.564
N/N N/N N/N
VESA
