Sony STR-DA1200ES Service Manual

2
STR-DA1200ES
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be
damaged by heat.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
Outputs
EQUALIZER
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo:
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz − 15 kHz, +0.5/−2 dB
Selectivity60 dB at 400 kHz
AM tuner section
Tuning range 531 − 1,602 kHz
(With 9-kHz tuning scale)
Antenna (aerial) Loop antenna (aerial)
Usable sensitivity 50 dB µ/m (at 999 kHz)
S/N54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity 35 dB
MD/TAPE, VIDEO1/2
(AUDIO OUT)
Vo l t age:150 mV
Impedance: 1 kohms
FRONT L/R, CENTER,
SURROUND L/R,
SURROUND BACK L/R,
SUB WOOFER
Vo l t age: 2 V
Impedance: 1 kohms
Gain levels ±10 dB, 1 dB step
Inputs (Digital)
DVD, SA-CD/CD
(Coaxial)
Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz
LPF)
VIDEO 1/3, TV/SAT,
MD/TAPE (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
Svideo: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
/C
B
: 0.7 Vp-p, 75 ohms
P
R
/C
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
General
Power requirements 230 V AC, 50/60 Hz
(in countries/areas in
Europe other than the UK)
240 V AC, 50/60 Hz
(in the UK and general
area)
Power consumption 440 W
Power consumption (during standby mode)
1 W
AC outlets 1 switched, 100 W/0.4A
MA
X
(Models for countries/areas
in Europe other than the UK)
Dimensions 430 × 175 × 430 mm
including projecting parts
and controls
Mass (Approx.) 15 kg
Supplied accessories
Operating Instructions (this manual)
Quick Setup Guide (1)
Optimizer microphone ECM-AC2 (1)
FM wire antenna (aerial) (1)
AM loop antenna (aerial) (1)
AC power cord (mains lead) (1)
Remote commander RM-AAP015 (1)
R6 (size-AA) batteries (2)
Design and specifications are subject to
change without notice.
70 dB

Sony STR-DA1200ES Specifications

General

Equalizer	Yes
Product color	Silver
Audio output channels	7.1 channels
Supported radio bands	AM, FM
I/O ports	5 x A/V In 2 x A/V Out 4 x S-Video In 1 x S-Video Out 3 x Component Video In 1 x Component Video Out 2 x HDMI In 1 x HDMI Out 4 x Opt.A/V In 1 x Opt.A/V Out
Connectivity technology	Wired
Headphone outputs	1
Dimensions (WxDxH)	430 x 175 x 430 mm
HDMI ports quantity	3

Weight and Dimensions

Weight	15000 g
