Sony STR-DE197 Service Manual

26
STR-DE197
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC OUTLET BOARD
****************
< AC OUTLET >
0CNJ901 1-785-285-11 OUTLET, AC (1P) (AC OUTLET) (AEP)
0CNJ901 1-785-834-11 OUTLET, AC (1P) (AC OUTLET) (US,CND)
< CONNECTOR >
CNP905 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
*************************************************************
A-4751-164-A DISPLAY BOARD, COMPLETE (US,CND)
A-4751-248-A DISPLAY BOARD, COMPLETE (AEP)
************************
* 4-921-941-01 CUSHION (FL)
* 4-943-107-11 HOLDER (FL TUBE)
< CAPACITOR >
C202 1-104-905-11 DOUBLE LAYERS 0.22F 5.5V
C203 1-164-159-11 CERAMIC 0.1uF 50V
C204 1-128-821-11 CERAMIC 0.001uF 5% 50V
C205 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP)
C206 1-127-876-11 CERAMIC 0.01uF 10% 50V
C207 1-128-821-11 CERAMIC 0.001uF 5% 50V
C208 1-128-821-11 CERAMIC 0.001uF 5% 50V
C209 1-128-821-11 CERAMIC 0.001uF 5% 50V
C210 1-128-821-11 CERAMIC 0.001uF 5% 50V
C211 1-127-876-11 CERAMIC 0.01uF 10% 50V
C212 1-127-876-11 CERAMIC 0.01uF 10% 50V
C213 1-127-876-11 CERAMIC 0.01uF 10% 50V
C215 1-126-947-11 ELECT 47uF 20% 35V
C216 1-126-795-11 ELECT 10uF 20% 50V
C217 1-128-821-11 CERAMIC 0.001uF 5% 50V
C218 1-128-821-11 CERAMIC 0.001uF 5% 50V
C219 1-126-794-11 ELECT 4.7uF 20% 50V
C221 1-128-821-11 CERAMIC 0.001uF 5% 50V
C222 1-128-821-11 CERAMIC 0.001uF 5% 50V
C225 1-164-159-11 CERAMIC 0.1uF 50V
C226 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP202 1-750-186-11 CONNECTOR, BOARD TO BOARD 6P
CNS4 1-784-776-11 CONNECTOR, FFC 15P (US,CND)
CNS4 1-784-778-11 CONNECTOR, FFC 17P (AEP)
CNS5 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
D203 8-719-061-96 LED SLR-325DCT31 (BASS BOOST)
D204 8-719-991-33 DIODE 1SS133T-77
< VACUUM FLUORESCENT DISPLAY >
FL201 1-518-970-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC201 6-801-553-01 IC uPD78045FGF-134-3B9
IC202 8-759-827-70 IC NJL64H400A-1 (IR)
< COIL >
L201 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-029-40 TRANSISTOR DTA124ESA
Q202 8-729-029-86 TRANSISTOR DTC124ESA
Q206 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R227 1-249-381-11 CARBON 1 5% 1/4W F
(AEP)
R227 1-249-389-11 CARBON 4.7 5% 1/4W F
(US,CND)
R228 1-249-381-11 CARBON 1 5% 1/4W F
(AEP)
R228 1-249-389-11 CARBON 4.7 5% 1/4W F
(US,CND)
R229 1-247-807-31 CARBON 100 5% 1/4W
R230 1-249-393-11 CARBON 10 5% 1/4W F
R231 1-247-807-31 CARBON 100 5% 1/4W
R232 1-247-807-31 CARBON 100 5% 1/4W
R233 1-247-807-31 CARBON 100 5% 1/4W
R234 1-247-807-31 CARBON 100 5% 1/4W
R235 1-247-807-31 CARBON 100 5% 1/4W
R236 1-247-807-31 CARBON 100 5% 1/4W
R237 1-247-807-31 CARBON 100 5% 1/4W
(AEP)
R238 1-249-429-11 CARBON 10K 5% 1/4W
R239 1-249-429-11 CARBON 10K 5% 1/4W
DISPLAY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
•Abbreviation
CND : Canadian model
AC OUTLET

Sony STR-DE197 Specifications

Audio

Channel Power Rating	100W x 2 (8 ohms, 40 Hz - 20kHz, THD 0.09%)
Sound Fields	Yes

Inputs and Outputs

RCA Audio Inputs	4 (Rear)
RCA Audio Outputs	2 (Rear)
AC Outlet	1 Switched
Antenna Terminal (AM Loop)	1 (Rear)
Antenna Terminal (FM 75 Ohm)	1 (Rear)
Headphone Output	1 (Front)

Power

Power Requirements	AC120V, 60 Hz
Power Consumption (in Operation)	190W
Power Consumption (in Standby)	0.5W

Weight and Dimensions

Weight	15 lbs 7 oz (7kg)
Measurements	16 13/14" x 5 3/14" x 11 8/9" (430 x 132.5 x 302mm)
