6
STR-K785
Rear panel
*You can watch the selected input image when you
connect the MONITOR OUT jack to a TV (page
17).
3
56
2
41
DVD IN
DIGITAL
OPTICAL
VIDEO 2
IN
VIDEO 1
IN
COAXIAL
SA-CD/CD
AUDIO IN
DVD
AUDIO IN
VIDEO 2
AUDIO IN
VIDEO IN VIDEO IN
AM
ANTENNA
SURROUND
SPEAKERS
LR
LR
+ +
CENTER FRONT
LR
LR
+ +
R
L
R
L
R
L
AUDIO
OUT
VIDEO 1
AUDIO IN
VIDEO IN
VIDEO OUT
SUB
WOOFER
MONITOR
COMPONENT VIDEO
DVD
IN
VIDEO 2
IN
MONITOR
OUT
Y
P
B /C B
P R /C R
A DIGITAL INPUT section
OPTICAL
IN jacks
Connects to a DVD
player, etc. The
COAXIAL jack
provides a better
quality of loud
sound (page 18,
20).
COAXIAL IN
jack
B ANTENNA section
FM
ANTENNA
jack
Connects to the
FM wire antenna
supplied with this
receiver (page 22).
AM
ANTENNA
terminals
Connects to the
AM loop antenna
supplied with this
receiver (page 22).
C VIDEO/AUDIO INPUT/OUTPUT
section
AUDIO IN
jacks
Connects the video
and audio jacks of
a VCR or a DVD
player (page 15,
17, 18, 19, 20, 21).
VIDEO IN/
OUT jacks*
White (L)
Red (R)
Ye llow
D COMPONENT VIDEO INPUT/
OUTPUT section
COMPONENT
VIDEO
INPUT/
OUTPUT
jacks*
Connects to a DVD
player, TV, or a
satellite tuner. You
can enjoy high
quality image
(page 17, 19, 20).
E SPEAKERS section
Connects to the
speakers (page 14).
Connects to the
sub woofer (page
14).
F AUDIO INPUT section
AUDIO IN
jacks
Connects to a CD
player, etc. (page
15).
Green
Blue
Red
White (L)
Red (R)
