NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 25 —
SECTION 5
ELECTRICAL PARTS LIST
* A-4407-853-A DISPLAY BOARD, COMPLETE
********************
* 4-921-941-01 CUSHION (FL)
* 4-979-943-01 HOLDER, FL TUBE
< CAPACITOR >
C401 1-162-306-11 CERAMIC 0.01uF 20% 16V
C402 1-162-306-11 CERAMIC 0.01uF 20% 16V
C403 1-124-903-11 ELECT 1uF 20% 50V
C404 1-124-903-11 ELECT 1uF 20% 50V
C405 1-126-934-11 ELECT 220uF 20% 10V
C406 1-124-907-11 ELECT 10uF 20% 50V
C407 1-124-907-11 ELECT 10uF 20% 50V
C408 1-164-159-11 CERAMIC 0.1uF 50V
C409 1-136-165-00 FILM 0.1uF 5% 50V
C410 1-164-159-11 CERAMIC 0.1uF 50V
C411 1-164-159-11 CERAMIC 0.1uF 50V
C412 1-161-494-00 CERAMIC 0.022uF 25V
C413 1-162-294-31 CERAMIC 0.001uF 10% 50V
C414 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
* CN401 1-568-848-11 SOCKET, CONNECTOR 5P
* CN402 1-568-867-11 SOCKET, CONNECTOR 25P
CN403 1-750-194-11 CONNECTOR, BOARD TO BOARD 4P
CN405 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
CN408 1-568-662-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D401 8-719-118-51 DIODE RD3.9F-T7B1
D402 8-719-911-19 DIODE 1SS119
D403 8-719-911-19 DIODE 1SS119
D404 8-719-911-19 DIODE 1SS119
D406 8-719-911-19 DIODE 1SS119
D407 8-719-313-45 DIODE SEL6810A-TH10 (TONE)
D408 8-719-313-45 DIODE SEL6810A-TH10 (CENTER)
D409 8-719-313-45 DIODE SEL6810A-TH10 (REAR)
D410 8-719-313-45 DIODE SEL6810A-TH10 (WOOFER)
D411 8-719-032-98 DIODE SEL5820A (SUPER WOOFER)
D412 8-719-032-98 DIODE SEL5820A (SUPER WOOFER)
D413 8-719-032-98 DIODE SEL5820A (DOLBY PRO LOGIC)
D414 8-719-032-98 DIODE SEL5820A (DOLBY PRO LOGIC)
D415 8-719-313-45 DIODE SEL6810A-TH10 (DOLBY)
D416 8-719-313-45 DIODE SEL6810A-TH10 (HALL)
D417 8-719-313-45 DIODE SEL6810A-TH10 (SIMULATED)
D418 8-719-313-45 DIODE SEL6810A-TH10 (STANDBY)
D419 8-719-911-19 DIODE 1SS119
< FILTER >
FL401 1-517-512-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC401 8-759-564-52 IC uPD78042FGF-089-3B9
IC402 8-759-165-81 IC PST600D-T
IC403 8-759-373-49 IC NJL54H400
< TRANSISTOR >
Q401 8-729-119-78 TRANSISTOR 2SC403SP-51
Q402 8-729-900-63 TRANSISTOR DTA124ES
Q403 8-729-900-36 TRANSISTOR DTC124ES
Q404 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R401 1-249-429-11 CARBON 10K 5% 1/4W
R402 1-249-429-11 CARBON 10K 5% 1/4W
R403 1-247-807-31 CARBON 100 5% 1/4W
R404 1-247-807-31 CARBON 100 5% 1/4W
R405 1-247-807-31 CARBON 100 5% 1/4W
R406 1-247-807-31 CARBON 100 5% 1/4W
R407 1-247-807-31 CARBON 100 5% 1/4W
R408 1-247-807-31 CARBON 100 5% 1/4W
R409 1-247-807-31 CARBON 100 5% 1/4W
R410 1-247-807-31 CARBON 100 5% 1/4W
R421 1-249-437-11 CARBON 47K 5% 1/4W
R422 1-249-437-11 CARBON 47K 5% 1/4W
R423 1-249-437-11 CARBON 47K 5% 1/4W
R424 1-249-437-11 CARBON 47K 5% 1/4W
R425 1-249-437-11 CARBON 47K 5% 1/4W
R426 1-249-437-11 CARBON 47K 5% 1/4W
R427 1-249-437-11 CARBON 47K 5% 1/4W
R428 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R430 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-437-11 CARBON 47K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R433 1-247-807-31 CARBON 100 5% 1/4W
R434 1-247-807-31 CARBON 100 5% 1/4W
R435 1-247-807-31 CARBON 100 5% 1/4W
R436 1-247-807-31 CARBON 100 5% 1/4W
R437 1-247-807-31 CARBON 100 5% 1/4W
R438 1-247-807-31 CARBON 100 5% 1/4W
R439 1-247-807-31 CARBON 100 5% 1/4W
R440 1-247-807-31 CARBON 100 5% 1/4W
DISPLAY
• Abbreviation
AUS : Australian model.
SP : Singapore model.
