• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-666-040-11 AC OUTLET BOARD
***************
< CONNECTOR >
* CN207 1-564-321-21 PIN, CONNECTOR 2P
CN208 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN209 1-564-321-00 PIN, CONNECTOR 2P
! CN210 1-251-597-11 OUTLET, AC (AC OUTLET)
< FUSE >
! F801 1-532-465-51 FUSE, TIME-LAG (3.15A/250V)
< FUSE HOLDER >
FH805 1-533-183-11 HOLDER, FUSE
FH806 1-533-183-11 HOLDER, FUSE
< TRANSFORMER >
! T801 1-431-369-11 TRANSFORMER, POWER
**************************************************************
* 1-663-769-11 AC SW BOARD
***********
< CAPACITOR >
! C810 1-113-920-11 CERAMIC 0.0022uF 20% 250V
< CONNECTOR >
CN801 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
! S801 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY)(POWER)
**************************************************************
* 1-663-768-11 HP BOARD
********
< CONNECTOR >
CN307 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J301 1-778-870-11 JACK (PHONES)
**************************************************************
* A-4392-944-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C501 1-136-810-11 FILM 220PF 5% 100V
C502 1-128-198-51 ELECT 22uF 20% 63V
C503 1-101-880-00 CERAMIC 47PF 5% 50V
C505 1-115-197-11 ELECT 100uF 20% 25V
C506 1-126-025-11 ELECT 330uF 20% 16V
C507 1-102-949-00 CERAMIC 12PF 5% 50V
C508 1-128-200-11 ELECT 47uF 20% 63V
C509 1-136-356-11 FILM 470PF 5% 100V
C510 1-126-025-11 ELECT 330uF 20% 25V
C511 1-115-197-11 ELECT 100uF 20% 25V
C512 1-136-810-11 FILM 220PF 5% 100V
C513 1-136-159-00 FILM 0.033uF 5% 50V
C514 1-136-356-11 FILM 470PF 5% 100V
C515 1-136-153-00 FILM 0.01uF 5% 50V
C516 1-136-153-00 FILM 0.01uF 5% 50V
C601 1-136-810-11 FILM 220PF 5% 100V
C602 1-128-198-51 ELECT 22uF 20% 63V
C603 1-101-880-00 CERAMIC 47PF 5% 50V
C605 1-115-197-11 ELECT 100uF 20% 25V
C606 1-126-025-11 ELECT 330uF 20% 16V
C607 1-102-949-00 CERAMIC 12PF 5% 50V
C608 1-128-200-11 ELECT 47uF 20% 63V
C609 1-136-356-11 FILM 470PF 5% 100V
C610 1-126-025-11 ELECT 330uF 20% 25V
C611 1-115-197-11 ELECT 100uF 20% 25V
C612 1-136-810-11 FILM 220PF 5% 100V
C613 1-136-159-00 FILM 0.033uF 5% 50V
C614 1-136-356-11 FILM 470PF 5% 100V
C615 1-136-153-00 FILM 0.01uF 5% 50V
C616 1-136-153-00 FILM 0.01uF 5% 50V
C701 1-106-343-00 MYLAR 1000PF 5% 200V
C702 1-106-343-00 MYLAR 1000PF 5% 200V
C703 1-106-343-00 MYLAR 1000PF 5% 200V
C704 1-106-343-00 MYLAR 1000PF 5% 200V
C705 1-106-343-00 MYLAR 1000PF 5% 200V
C706 1-106-343-00 MYLAR 1000PF 5% 200V
C707 1-124-916-11 ELECT 22uF 20% 63V
C708 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C709 1-126-052-11 ELECT 100uF 20% 25V
C710 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C711 1-124-927-11 ELECT 4.7uF 20% 100V
C712 1-126-052-11 ELECT 100uF 20% 25V
