Sony TA-S9D Service Manual

7
TA-S9D
3-4. BACK PANEL (DVD) SECTION
3-5. FRONT AMP BOARD
5 three screws
(BVTP3
× 8)
5 four screws
(BVTP3
× 8)
5 four screws
(BVTP3 × 8
)
4 RELAY board
3 two connectors
(CN106, 113)
6 connector
(CN105)
7 three connectors
(CN901, 902, 903)
1 screw
(BVTP3 × 8)
8 back panel (DVD) section
6
1 screw
(BVTP3 × 8)
2 lug
2 screw
(BVTP3
× 8)
5 screw
(BVTP3
× 8)
4 two screws
(BVTT3
× 8)
3 bracket (PWB)
6 lug
8 Remove the FRONT AMP boar
d
in the direction of the arrow.
7 PC board holder
1 three connector
(CN913, 914, 915)
7 PC board holder
