TA-SA300WR
SECTION 6
ELECTRICAL PARTS LIST
A-1795-554-A POWER BOARD, COMPLETE (US, CND)
A-1795-643-A POWER BOARD, COMPLETE (AEP, IT, UK, AUS)
**********************
3-077-331-11 +BV3 (3-CR)
< CAPACITOR >
0 C900 1-165-529-11 MYLAR 0.22uF 10% 250V
(US, CND)
0 C902 1-165-528-11 MYLAR 0.1uF 10% 250V
(AEP, IT, UK, AUS)
0 C903 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND)
0 C904 1-112-869-51 CERAMIC 470PF 10% 250V
(AEP, IT, UK, AUS)
0 C905 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND)
0 C906 1-112-869-51 CERAMIC 470PF 10% 250V
(AEP, IT, UK, AUS)
0 C907 1-112-866-51 CERAMIC 100PF 10% 250V
(US, CND)
0 C907 1-112-869-51 CERAMIC 470PF 10% 250V
(AEP, IT, UK, AUS)
0 C911 1-116-393-21 FILM 0.0033uF 5% 400V
0 C914 1-107-932-91 ELECT 47uF 20% 100V
0 C916 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
0 C917 1-107-903-91 ELECT 2.2uF 20% 50V
0 C919 1-107-902-91 ELECT 1uF 20% 50V
0 C920 1-116-392-21 FILM 0.01uF 5% 400V
(US, CND)
0 C921 1-116-393-21 FILM 0.0033uF 5% 400V
(AEP, IT, UK, AUS)
0 C922 1-125-893-11 FILM 680PF 3% 1.5KV
(AEP, IT, UK, AUS)
0 C923 1-117-631-11 FILM 3300PF 3% 1.2KV
(US, CND)
0 C924 1-107-906-91 ELECT 10uF 20% 50V
0 C925 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
0 C927 1-107-909-91 ELECT 47uF 20% 50V
0 C928 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
0 C929 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
0 C930 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
0 C931 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
0 C932 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
0 C935 1-100-922-11 ELECT 330uF 20% 200V
(US, CND)
0 C936 1-100-923-11 ELECT 100uF 20% 450V
(AEP, IT, UK, AUS)
0 C937 1-165-528-11 MYLAR 0.1uF 10% 250V
C940 1-125-782-91 CERAMIC 4700PF 10% 1KV
C941 1-112-254-11 ELECT 1000uF 20% 35V
C943 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C944 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C946 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C947 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C951 1-112-222-11 ELECT 2200uF 20% 10V
C952 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C953 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C954 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C960 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
0 CN900 1-564-321-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CN901 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
< DIODE >
0 D900 8-719-077-77 DIODE D3SB60F3
0 D901 8-719-063-74 DIODE D1NL20U-TR2
0 D902 6-502-961-01 DIODE DA2J10100L
0 D910 6-501-297-01 DIODE 1F6G
0 D911 8-719-063-74 DIODE D1NL20U-TR2
0 D912 6-503-022-01 DIODE DZ2J100M0L
0 D913 6-503-037-01 DIODE DZ2J24000L
0 D914 8-719-083-71 DIODE UDZSUSTE-1730B
0 D915 8-719-069-61 DIODE UDZSUSTE-1710B
0 D916 6-503-015-01 DIODE DZ2J051M0L
0 D920 6-500-241-01 DIODE SARS03
0
D922 6-503-034-01
DIODE DZ2J200M0L
0 D923 6-502-961-01 DIODE DA2J10100L
0 D924 8-719-063-74 DIODE D1NL20U-TR2
0 D925 6-502-961-01 DIODE DA2J10100L
0 D926 6-502-961-01 DIODE DA2J10100L
0 D927 8-719-069-56 DIODE UDZSUSTE-176.2B
0 D928 6-502-968-01 DIODE DZ2J062M0L
0 D929 6-502-961-01 DIODE DA2J10100L
0 D930 6-503-042-01 DIODE DZ2J330M0L
0 D931 6-502-970-01 DIODE DZ2J068M0L (AEP, IT, UK, AUS)
0 D932 6-503-022-01 DIODE DZ2J100M0L
D940 6-501-849-01 DIODE FMX-22SL
D950 8-719-080-53 DIODE RK36LF-B3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
IT : Italian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Ver. 1.1
