Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TA-SA300WR
2525
C122 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C125 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C127 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C129 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C130 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C131 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C132 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C134 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C135 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C136 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C137 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C138 1-112-246-11 ELECT 100uF 20% 35V
C140 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C141 1-126-923-91 ELECT 220uF 20% 10V
C143 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C144 1-114-885-51 FILM 1uF 5% 50V
C145 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C147 1-114-885-51 FILM 1uF 5% 50V
C148 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C152 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C154 1-112-246-11 ELECT 100uF 20% 35V
C155 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C156 1-112-831-31 ELECT 2200uF 20% 35V
C157 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C158 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C159 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C161 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C162 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C163 1-112-246-11 ELECT 100uF 20% 35V
C165 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C166 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C167 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C169 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C170 1-104-656-11 ELECT 2200uF 20% 6.3V
C172 1-114-885-51 FILM 1uF 5% 50V
C173 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C174 1-114-885-51 FILM 1uF 5% 50V
C175 1-104-658-91 ELECT 100uF 20% 10V
C177 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C178 1-104-658-91 ELECT 100uF 20% 10V
C179 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C180 1-112-246-11 ELECT 100uF 20% 35V
C182 1-112-831-31 ELECT 2200uF 20% 35V
C184 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C185 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C186 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C187 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C188 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C189 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C190 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C191 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C193 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C194 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C195 1-104-962-91 ELECT 47uF 20% 35V
C196 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C197 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C198 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C199 1-107-882-91 ELECT 100uF 20% 16V
C200 1-104-655-91 ELECT 470uF 20% 6.3V
C201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-838-505-11 CONNECTOR, CARD EDGE 30P (L)
CN102 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D101 6-502-961-01 DIODE DA2J10100L
D111 6-502-961-01 DIODE DA2J10100L
D112 6-502-966-01 DIODE DZ2J056M0L
< FERRITE BEAD >
FB101 1-400-697-31 BEAD, FERRITE (CHIP) (1608)
< IC >
IC100 A-1795-558-A IC R5F212BASNFP (for SERVICE)
IC101 6-715-382-01
IC PST8435UL
IC103 6-707-856-01 IC TC74LCX74FT (EKJ)
IC104 6-714-477-01 IC CXD9981TN
IC105 6-707-939-01 IC CXD9843AR
IC106 6-714-743-01 IC MM3404A18URE
IC107 6-706-492-01 IC TC7SHU04FU
IC108 6-711-049-01 IC S-1170B33UC-OTSTFG
IC109 6-712-613-01 IC SI-3010KM-TLS
< COIL >
L100 1-457-579-11 INDUCTOR 10uH
L101 1-457-579-11 INDUCTOR 10uH
< TRANSISTOR >
Q102 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q103 6-551-272-01 TRANSISTOR RT3CLLM
Q104 6-551-272-01 TRANSISTOR RT3CLLM
Q105 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q106 6-551-271-01 TRANSISTOR RT3AMMM
Q107 6-551-271-01 TRANSISTOR RT3AMMM
Q108 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q109 6-551-690-01 TRANSISTOR RT3N11M-TP-1
Q110 6-550-363-01 TRANSISTOR 2SB1690KT146
Q111 6-551-691-01 TRANSISTOR RT3P11M-TP-1
Q112 8-729-038-37 TRANSISTOR RT1N141M-TP-1
< RESISTOR >
R103 1-218-953-11 METAL CHIP 1K 5% 1/16W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R109 1-218-965-11 METAL CHIP 10K 5% 1/16W
R110 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R112 1-218-973-11 METAL CHIP 47K 5% 1/16W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-218-977-11 METAL CHIP 100K 5% 1/16W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R118 1-218-973-11 METAL CHIP 47K 5% 1/16W
R119 1-216-833-11 METAL CHIP 10K 5% 1/10W
R120 1-216-864-11 SHORT CHIP 0
R121 1-218-965-11 METAL CHIP 10K 5% 1/16W
R125 1-216-809-11 METAL CHIP 100 5% 1/10W
WLK4 MAIN
